The ATN ThOR 6 Mini is a compact thermal optic built around a 12 µm VOx uncooled focal plane array and a 256×192 sensor configuration. It provides variable magnification for a range of observation tasks and includes onboard video recording, Wi‑Fi hotspot capability, and a rugged IP67-rated housing for field use. The design focuses on practical, high-performance thermal imaging without unnecessary complexity.
Key Specifications
- Magnification ranges from 2–16x to cover close‑to‑mid distance observation and engagement scenarios.
- Sensor resolution is 256×192 on this configuration for thermal detection and imaging.
- Detector type uses a 12 µm VOx uncooled focal plane array for thermal sensitivity.
- Frame rate operates at 50 Hz to deliver smooth image updates and tracking.
- Thermal sensitivity (NETD) rated at ≤20 mK for the 256×192 configuration to reveal subtle heat differences.
- Objective lens is a 15 mm, F/1.0 optical assembly optimized for the sensor size.
- Onboard display is a 0.32-inch OLED at 800×600 resolution for clear image presentation.
- Internal storage includes 64 GB with video and audio recording plus Recoil Activated Video (RAV).
- Power uses 1×18650 rechargeable battery (replaceable) with approximately ~8 hours runtime per charge under typical conditions.
- Environmental protection is rated IP67 for dust and water resistance suitable for harsh field conditions.
The ThOR 6 Mini combines core thermal imaging features—stable magnification, high-sensitivity detection, onboard recording, and wireless connectivity—in a compact magnesium-alloy housing. Its feature set is tailored for informed users who require reliable thermal observation and documentation capability in a lightweight package.
This description was generated with AI and may contain errors. Verify specifications and legal restrictions with the manufacturer before purchase. Provided “as-is” without warranties or guarantees.
